As a Managed Service Provider (MSP), CoNetrix Technology has helped many customers secure their IT infrastructure against malware, and occasionally responded to malware attacks to stop or limit the damage. The purpose of this case study is to describe a specific malware attack against one of our customers and how the attack was successfully blocked. The goal is to provide information to other organizations so they can learn from this specific attack and better protect their IT environment.
A new organization fell victim to ransomware every 14 seconds in 2019
and is estimated it will be every 11 seconds in 2021.
(CyberSecurity Ventures)
Phishing emails are the
vector for two-thirds of
ransomware infections.
(Statista)
46% of ransomware
operators impersonate
authority figures such
as the FBI or the IRS.
(Stanford University)
eCrime, defined as
criminal activities in order
to generate revenue, have
increased to 79% of all
intrusions between 2019
and 2020. (CrowdStrike
2021 Global Threat Report)
As a Managed Service Provider (MSP), CoNetrix Technology has helped many customers secure their IT infrastructure against malware, and occasionally responded to malware attacks to stop or limit the damage. The purpose of this case study is to describe a specific malware attack against one of our customers and how the attack was successfully blocked. The goal is to provide information to other organizations so they can learn from this specific attack and better protect their IT environment.
Windows 10 virtual desktops available through Citrix
Cloud and a hosted Citrix Remote Access Gateway.
Windows servers running on VMware vSphere.
Endpoint protection provided through CoNetrix
Technology, based on CylanceProtect and CylanceOptics.
Email hosted with a different service provider using basic email filtering.
FortiGate Unified Threat Management appliance installed on the customer premise and managed by CoNetrix.
Every IT environment is slightly different, so strategies described in this case study may not apply to your situation.
Similarly, every attack is different, and the attack vectors are constantly changing. So over time the responses we describe in this case study may not apply for future attacks.
We are not disclosing any customer-specific information
to protect their confidentiality and prevent making them
a target for future attacks.
At the beginning of this malware attack, our first Indicator of Compromise (IOC) was multiple alerts through the Cylance monitoring portal of attempts to install executables named like “remote.exe.” These were targeted at the virtual desktops hosted through Citrix.
Thankfully the attempts were blocked by Cylance, but the attackers continued with different executables trying to gain a foothold. Our research on these quarantined executables through tools like VirusTotal did not match any previously known malware.
Our initial response was to locate the source of the attack by increasing logging through Cylance, implement egress filtering on the Fortigate, and review logs on the Fortigate and the Citrix gateway. We also requested the customer have their employees change their password immediately.
During our investigation, the
attackers
changed their tactics...
During our investigation, the attackers changed their tactics by moving to PowerShell based compromises and moving laterally by targeting different virtual desktops and different user accounts. As before, these attacks were blocked by Cylance. These changes in the attack vector provided some key information:
This was not a simple automated attack. The bad actors were
actively changing their approach
in order to get a successful compromise.
Multiple user passwords were likely hacked because the bad actors
were attempting multiple accounts and we were not seeing failed
logins in the domain security logs.
This activity continued over the next two days, and we were able to completely stop the attack by forcing all users to change their domain password and blocking IP subnets to the Citrix remote access gateway, which effectively cut off the bad actor’s access to the virtual desktops. During the attack, no systems were compromised and all malware was stopped by Cylance.
During the attack, no systems were compromised
and all malware was stopped by Cylance.
After completing our research into this incident we believe the attack began and progressed as follows:
Step 1: The attackers gained access to at least one user account through a phishing email. Unfortunately, one of these accounts had domain administrator privileges.
Step 2: Using this account, the attackers were able to download the hash table to gain access to all user passwords.
Step 3: With these passwords they accessed the virtual desktops through the Citrix gateway.
Step 4: After they were unsuccessful in deploying the malware, they moved to other accounts and virtual desktops.
Step 5: The attack was stopped when the user passwords were changed and the source IP addresses blocked.
While Cylance was effective in this situation and no malware was allowed to run, we recommended several improvements to the customer:
Conduct security awareness training for all employees to help them identify phishing emails and avoid clicking on links in emails.
Implement multi-factor authentication for remote access through the Citrix gateway. This would make it much more difficult to access a virtual desktop remotely if an account is compromised.
Upgrade their email filtering solution with URL protection and active sandboxing of downloaded attachments.
Limit the number of users with domain admin access, and not allow use of a domain admin account for regular “everyday” access.
Strengthen policies for password length and complexity to make passwords less susceptible to cracking.
There are some additional key takeaways from this attack that apply to every IT environment:
Add Multiple Security Layers
The best IT security consists of multiple layers and does not rely
on a single technology. As an example, while Cylance worked in this
situation, it would be risky to assume that any endpoint protection
solution would be 100% effective in every attack.
Create an Incident Response Plan
An Incident Response (IR) procedure should be defined in advance
so you can respond quickly and efficiently to security incidents.
This includes procedures for working with your IT vendor and your
employees.
Implement Endpoint Protection with Machine Learning
Signature-based endpoint protection solutions are largely ineffective.
This attack demonstrated that malware can be easily modified to circumvent
any known signatures. An effective endpoint protection solution must
use machine learning and behavioral analysis to stop current attacks.
Cylance, CrowdStrike, and SentinelOne are the market leaders for
this type of solution.
Require Multi-Factor Authentication
Two-Factor Authentication (2FA) or Multi-Factor Authentication (MFA)
should be required for any external access to the network and access
to any public cloud services, such as Microsoft 365. Despite our
best efforts, end-users are not reliable for creating strong, secure
passwords. MFA solutions such as Duo Security, RSA, and Google Authenticator
can be effective defenses against a compromised password.
If you are interested in implementing any of these services, please contact us . A representative of CoNetrix Technology can match a solution to your specific situation.
Malware attacks are constantly evolving, and IT administrators must adapt in order to protect their business. Hopefully, this case study demonstrates the value of a layered approach to IT security in order to provide the best protection.
